Orange Smooth Polyurethane Round Belt PU Round Belt SGS ISO9001: 2008 Certified Diameter 2-20mm

  • Orange Smooth Polyurethane Round Belt PU Round Belt SGS ISO9001: 2008 Certified Diameter 2-20mm
مقدار حداقل تعداد سفارش 1000
قیمت 0.5

برای نمونه و کوپن رایگان با من تماس بگیرید.

واتساپ:0086 18588475571

وی چت: 0086 18588475571

اسکایپ: sales10@aixton.com

اگر نگرانی دارید، ما به صورت آنلاین 24 ساعته راهنمایی می کنیم.

x
جزئیات محصول
شماره شماره Dia 2mm-20mm نوع کمربند گرد PU
مادی پید مواد داخل پید
سطح صاف یا خشن استحکام کششی 55 نیوتن بر میلی متر مربع
قطر 2 ~ 20 میلی متر سختی 85 A 90 ~
میزان کشش 1.5-3٪ کمترین شعاع 20-160 میلی‌متر
حداکثر کششی 0.3-31.3 کیلوگرم طول رول 30-400 متر
مقاومت در برابر سایش برجسته استحکام اشک عالی
مقاومت در برابر ضربه عالی
برجسته کردن

SGS ISO9001: 2008 Certified Polyurethane Round Belt,Diameter 2-20mm PU Round Belt,Orange Polyurethane Round Belt

,

Diameter 2-20mm PU Round Belt

,

Orange Polyurethane Round Belt
پیام بگذارید
توضیحات محصول
Orange Smooth Polyurethane Round Belt

Our premium Polyurethane round belts are designed for transmission applications in industrial machinery and product conveyance systems. These belts feature a durable poly cord construction and are available with both smooth and rough surfaces to suit various operational requirements.

Product Features
  • Outstanding abrasion resistance
  • High tensile and tear strength
  • Resistance to oils, fuels, and oxygen
  • Excellent weatherability and high impact resistance
  • Low compression set for long-term performance
  • Available with polyester, nylon, or fiber reinforcement
  • Can be welded to form O-rings
Applications

Ideal for use in:

  • Newspaper conveying systems
  • Packaging machinery
  • Ceramic and stoneware processing plants
  • Floor and roof tile conveyance
  • Wood working machinery
  • Textile machines
  • Paper industry equipment
  • Food grading and processing machines
Technical Specifications
Items NO. Φ Least Radius of Gyration Stretching Rate Maximum Tensile Rate Hardness Length of Roll
DIA(mm) In mm % Kg Lbs Shore(A) Roll(m)
2mm 0.79 20 1.5-3% 0.3 0.7 95 400
2.5mm 0.87 22 1.5-3% 0.4 0.9 95 400
3mm 0.98 25 1.5-3% 0.7 1.6 90 400
3.5mm 1.18 30 1.5-3% 0.95 2.1 90 400
4mm 1.38 35 1.5-3% 1.2 2.7 90 200
5mm 1.57 40 1.5-3% 2 4.3 90 100
6mm 1.97 50 1.5-3% 3.2 7 90 100
7mm 2.17 55 1.5-3% 4.1 9 90 100
8mm 2.56 65 1.5-3% 5 11 90 100
9mm 2.95 75 1.5-3% 6.8 15 90 50
10mm 3.94 100 1.5-3% 7.7 17 90 50
12mm 3.94 100 1.5-3% 12.2 27 90 30
15mm 4.72 120 1.5-3% 17.7 39 90 30
18mm 5.71 145 1.5-3% 25.4 56 90 30
20mm 6.3 160 1.5-3% 31.3 69 90 30

Note: We also supply connecting tools and accessories for polyurethane belts, including clamps, electric irons, and knives. Connection methods include hot press welding and overlap welding.
