Conveyor High Density Polyurethane Round Belt Wear Resistant

چین Wuxi Jiunai Polyurethane Products Co., Ltd گواهینامه ها
چین Wuxi Jiunai Polyurethane Products Co., Ltd گواهینامه ها
Customer satisfaction products , good service !

—— Mr. Alcioni possamai

we are very impressed with the quality of the belts you produced.

—— Mr.Mike

your products are very popular in my markets.

—— Mr. jone

چت IM آنلاین در حال حاضر

Conveyor High Density Polyurethane Round Belt Wear Resistant

Conveyor High Density Polyurethane Round Belt Wear Resistant
Conveyor High Density Polyurethane Round Belt Wear Resistant Conveyor High Density Polyurethane Round Belt Wear Resistant Conveyor High Density Polyurethane Round Belt Wear Resistant Conveyor High Density Polyurethane Round Belt Wear Resistant

تصویر بزرگ :  Conveyor High Density Polyurethane Round Belt Wear Resistant

جزئیات محصول:
Place of Origin: China
نام تجاری: jiuna
گواهی: ROHS
Model Number: Diameter 5mm~15mm
پرداخت:
Minimum Order Quantity: 10rolls
Packaging Details: Inner packing is plastic film .outer packing is carton .
Delivery Time: Within 5 working days After receipt of your deposit
Payment Terms: T/T, 50% payment in advance ,50% balance before shipment ; Western Union ; L/C
Supply Ability: 96.000 meters per Month
توضیحات محصول جزئیات
tensile rate: 0.3kg-31.3kg color: green or as your require
stretching rate: 1.5%-3% material: PU
longth: 400m/roll 200m/roll 100m/roll 30m/roll hardness: 85A-90A
برجسته:

,

,

pu extruded belt

Conveyor High Density Polyurethane Round Belt Wear Resistant

Detailed Product Description:

PU Cord Belt Application :

 (1) printing and packing machine

 (2) food & beverage processing

 (3) wood processing

 (4) paper processing

 (5) electronic

 (6) post service

 (7) tobacco transmission line

PU Cord Properties :

(1)Excellent abrasion resistance.

(2)Good resistance to fuel , oils and oxygen.

(3)Contains no plasticizer.

(4)Wide application temperature from -30℃~+80℃

Our company specializing in the production of PU round belt,V belt,non-slip belt,wire clip,clip wire core,PU guide, stop,package edge,skirt,scraping gum,rubber roller,wheel and all kinds of non-standard special polyurethane products.TPU proudcts characteristic and main performance are: easy adhesion,good abrasion resistance,tear resistance,bending strength,tensile strength and breaking elongation,heat-resistant moderate (-30 ℃~80℃ ) ,hardness shaw (70a~98a). Smooth round belt, V belt surface finish is good, bright color with rough surface. Uniform praticles,comfortable feel.cpu pouring product characteristics and main performance are: wear-resisting.oil,acid and alkali resistance,solvent resistance,ozone resistance,aging resistance,environmental protection,non-toxic,the main products are rubber roller plastic bags,plastic core package iron roller,printing and dyeing,etc.,and can undertake various non-standard parts processing,customized non-standard products can be according to the drawing,plastic,iron core production in a body.

transmission Round Belting :

Items No. φ least radius of gyration stretch rate Maximum tensile rate Hardness length of rolled

DIA

(mm)

In mm Stretching rate Kg Lbs

Hardness

(A)

Roll

(m)

2 0.79 20 mm 1.5-3% 0.3 0.7 90 400
3 0.98 25  mm 1.5-3% 0.7 1.6 90 400
4 1.38 35  mm 1.5-3% 1.2 2.7 85 200
5 1.57 40  mm 1.5-3% 2.0 4.3 85 100
6 1.97 50  mm 1.5-3% 3.2 7.0 85 100
7 2.17 55  mm 1.5-3% 4.1 9.0 85 100
8 2.56 65  mm 1.5-3% 5.0 11.0 85 100
9 2.95 75  mm 1.5-3% 6.8 15.0 85 50
10 2.95 75  mm 1.5-3% 7.7 17.0 85 50
12 3.94 100 mm 1.5-3% 12.2 27.0 85 30
15 4.72 120 mm 1.5-3% 17.7 39.0 85 30
18 5.71 145 mm 1.5-3% 25.4 56.0 85 30
20 6.30 160 mm 1.5-3% 31.3 69.0 85

30







Conveyor High Density Polyurethane Round Belt Wear Resistant 0Conveyor High Density Polyurethane Round Belt Wear Resistant 1
