Industrial Polyurethane Round Belt , Transmission Conveying Seamless Round Belt 10 × 945mm

چین Wuxi Jiunai Polyurethane Products Co., Ltd گواهینامه ها
چین Wuxi Jiunai Polyurethane Products Co., Ltd گواهینامه ها
Customer satisfaction products , good service !

—— Mr. Alcioni possamai

we are very impressed with the quality of the belts you produced.

—— Mr.Mike

your products are very popular in my markets.

—— Mr. jone

چت IM آنلاین در حال حاضر

Industrial Polyurethane Round Belt , Transmission Conveying Seamless Round Belt 10 × 945mm

Industrial Polyurethane Round Belt , Transmission Conveying Seamless Round Belt 10 × 945mm
Industrial Polyurethane Round Belt , Transmission Conveying Seamless Round Belt 10 × 945mm Industrial Polyurethane Round Belt , Transmission Conveying Seamless Round Belt 10 × 945mm Industrial Polyurethane Round Belt , Transmission Conveying Seamless Round Belt 10 × 945mm

تصویر بزرگ :  Industrial Polyurethane Round Belt , Transmission Conveying Seamless Round Belt 10 × 945mm

جزئیات محصول:
Place of Origin: China
نام تجاری: Jiuna
گواهی: ROHS
Model Number: Diameter 2mm~20mm
پرداخت:
Minimum Order Quantity: 500piece
Packaging Details: Inner packing is plastic film .outer packing is carton
Delivery Time: Within 5 working days After receipt of your deposit
Payment Terms: T/T, 50% payment in advance ,50% balance before shipment
Supply Ability: 6000 piece per Month
Factory: Wuxi City
توضیحات محصول جزئیات
hardness: 85A-90A color: green
diameter: 10mm size: 10*945mm
type: eamless belt material: PU
برجسته:

,

,

pu extruded belt

Industrial Polyurethane Round Belt , Transmission Conveying Seamless Round Belt 10 × 945mm

Products introduction:

We offer a complete line of Polyester and Polyurethane Round belts for use in industrial machines. And In the conveyance of products ranging from transport machine,conveyor machine to glass and tile.

The very elastic and flexible material PU 85 A ~90 A is particularly suitable for lead in conveyors and vertical shafts .

Round belts are available with smooth and rough surfaces and reinforced with polyester, nylon or fibers. Also can welding belt to O-ring . supply the connecting tools & Accessories for polyurethane belts ,

including clamp ,the Electric Iron and Knife , Connecting methods is butt joint welding , overlap welding .

Endless Cord Application :



Application:

Newspaper conveying,
Packing machines,
Ceramic and stoneware processing plants,
Floor and roof tiles conveying,
Wood Working machineries,
Textile machines,
Paper industry machines,
Food grading machines, other food processing machines.



 Features

Outstanding abrasion resistance
High tensile and tear strength
Resistance to oils, fuels,and oxygen
Good weatherability and high impact resistance
Low compression set





Items NO.Φ

Least radius of gyration

Stretching rate

Maximum tensile rate

Hardness

Length of rolled

DIA(mm)

 In

mm

  %

Kg

Lbs

Shore( A)

Length of rolled

2mm

0.79

20

1.5-3%

0.3

0.7

95

400

2.5mm

0.87

22

1.5-3%

0.4

0.9

95

400

3mm

0.98

25

1.5-3%

0.7

1.6

90

400

3.5mm

1.18

30

1.5-3%

0.95

2.1

90

400

4mm

1.38

35

1.5-3%

1.2

2.7

90

200

5mm

1.57

40

1.5-3%

2.0

4.3

90

100

6mm

1.97

50

1.5-3%

3.2

7.0

90

100

7mm

2.17

55

1.5-3%

4.1

9.0

90

100

8mm

2.56

65

1.5-3%

5.0

11.0

90

100

9mm

2.95

75

1.5-3%

6.8

15.0

90

50

10mm

2.95

75

1.5-3%

7.7

17.0

90

50

12mm

3.94

100

1.5-3%

12.2

27.0

90

30

15mm

4.72

120

1.5-3%

17.7

39.0

90

30

18mm

5.71

145

1.5-3%

25.4

56.0

90

30

20mm

6.30

160

1.5-3%

31.3

69.0

90

30



Service commitment:

“Quality for keeping going ,Credit to win the world”
