Tensile Strength Breaking elongation Green Polyurethane Round Belt for Industry Machines

چین Wuxi Jiunai Polyurethane Products Co., Ltd گواهینامه ها
چین Wuxi Jiunai Polyurethane Products Co., Ltd گواهینامه ها
Customer satisfaction products , good service !

—— Mr. Alcioni possamai

we are very impressed with the quality of the belts you produced.

—— Mr.Mike

your products are very popular in my markets.

—— Mr. jone

چت IM آنلاین در حال حاضر

Tensile Strength Breaking elongation Green Polyurethane Round Belt for Industry Machines

Tensile Strength Breaking elongation Green Polyurethane Round Belt  for Industry Machines
Tensile Strength Breaking elongation Green Polyurethane Round Belt  for Industry Machines Tensile Strength Breaking elongation Green Polyurethane Round Belt  for Industry Machines Tensile Strength Breaking elongation Green Polyurethane Round Belt  for Industry Machines Tensile Strength Breaking elongation Green Polyurethane Round Belt  for Industry Machines

تصویر بزرگ :  Tensile Strength Breaking elongation Green Polyurethane Round Belt for Industry Machines

جزئیات محصول:
Place of Origin: China
نام تجاری: Jiuna
گواهی: ROHS
Model Number: Diameter 2mm~20mm
پرداخت:
Minimum Order Quantity: 10rolls
Packaging Details: Inner packing is plastic film .outer packing is carton .
Delivery Time: Within 5 working days After receipt of your deposit
Payment Terms: T/T, 50% payment in advance ,50% balance before shipment
Supply Ability: 96.000 meters per Month
Export port: Shanghai ,China
Factory: Wuxi City
توضیحات محصول جزئیات
radius of gyration: 0.79in-6.3in Material: PU
stretching rate: 1.5%-3% tensile rate: 0.7 lbs-69lbs
longth/ roll: 400m 300m 200m 100m 30m color: green
برجسته:

,

,

pu extruded belt

Industrial Transmission Conveyor green rough PU Cord polyurethane round belt

PU Cord Belt Application :

 1.   Widely used in textile

 2.   printing and packing machine

 3.   food & beverage processing

 4.   wood processing

 5.   paper processing

 6.   electronic

 7.   post service

 8.   tobacco transmission line

 9.   Wall floor tile conveying industrial line

10.  Ceramic industry line or polishing line



PU Cord Properties :

-High tensile strength

-Excellent abrasion resistance

-Good resistance to fuel , oils and oxygen

-Contains no plasticizer

-Wide application temperature from -30℃~+80℃



Our company specializing in the production of PU round belt,V belt,non-slip belt,wire clip,clip wire core,PU guide, stop,package edge,skirt,scraping gum,rubber roller,wheel and all kinds of non-standard special polyurethane products.TPU proudcts characteristic and main performance are: easy adhesion,good abrasion resistance,tear resistance,bending strength,tensile strength and breaking elongation,heat-resistant moderate (-30 ℃~80℃ ) ,hardness shaw (70a~98a). Smooth round belt, V belt surface finish is good, bright color with rough surface. Uniform praticles,comfortable feel

Products introduction:

The very elastic and flexible material PU 85 A ~90 A is particularly suitable for lead in conveyors and vertical shafts .

We offer a complete line of Polyester and Polyurethane Round belts for use in industrial machines. And In the conveyance of products ranging from transport machine,conveyor machine to glass and tile. Round belts are available with smooth and rough surfaces and reinforced with polyester, nylon or fibers. Also can welding belt to O-ring . supply the connecting tools & Accessories for polyurethane belts , include clamp ,the Electric Iron and Knife , Connecting methods is butting joint welding , overlap welding .

Service commitment:

“Quality for keeping going ,Credit to win the world”



Items No. φ

least radius of gyration

stretch rate

Maximum tensile rate

Hardness

length of rolled

DIA

(mm)

In

mm

Stretching rate

Kg

Lbs

Hardness

(A)

Roll

(m)

2mm

0.79

20mm

1.5-3%

0.3

0.7

90

400

3mm

0.98

25mm

1.5-3%

0.7

1.6

90

400

4mm

1.38

35mm

1.5-3%

1.2

2.7

85

200

5mm

1.57

40mm

1.5-3%

2.0

4.3

85

100

6mm

1.97

50mm

1.5-3%

3.2

7.0

85

100

7mm

2.17

55mm

1.5-3%

4.1

9.0

85

100

8mm

2.56

65mm

1.5-3%

5.0

11.0

85

100

9mm

2.95

75mm

1.5-3%

6.8

15.0

85

50

10mm

2.95

75mm

1.5-3%

7.7

17.0

85

50

12mm

3.94

100mm

1.5-3%

12.2

27.0

85

30

15mm

4.72

120mm

1.5-3%

17.7

39.0

85

30

18mm

5.71

145mm

1.5-3%

25.4

56.0

85

30

20mm

6.30

160mm

1.5-3%

31.3

69.0

85

30





Tensile Strength Breaking elongation Green Polyurethane Round Belt  for Industry Machines 0Tensile Strength Breaking elongation Green Polyurethane Round Belt  for Industry Machines 1
