جزئیات محصول:
پرداخت:
|
color: | green orange | material: | PU |
---|---|---|---|
longth: | 300m/roll 200m/roll 100m/roll 30m/roll | hardness: | 85A-90A |
tensile rate: | 0.3kg-31.3kg | type: | round belt |
برجسته: | ,,green round belt |
Rough Transmission Polyurethane Round Belt For Packing machine
Detailed Product Description:
PU Cord Belt Application :
1. Wall floor tile conveying industrial line
2. printing and packing machine
3. food & beverage processing
4. wood processing
5. paper processing
6. electronic
7. post service
8. tobacco transmission line
PU Cord Properties :
-Excellent abrasion resistance.
-Good resistance to fuel , oils and oxygen.
-Contains no plasticizer.
-Wide application temperature from -30℃~+80℃
1.24 hours technical support by email
2.Professional After-sales service
3. ISO9001:2000 and TS16949 certificated.
4. OEM available.
5. More than ten years of sales and manufacture experience
6.100% test for air pressure and inspection for product appearance before shipment.
7. Long lifespan, competitive price.
8. Good payment term.
9. Fast delivery.
10.Thread Standard: BSPP, BSPT, NPT, METRIC etc. Our products are exported to more than
30 countries in the whole world.
11. Our products are showed at international fair, such as Germany, Italy, America, Brazil,
Dubai,
Russia, Shanghai China fair etc each year.
12. Location advantage: Nearby Ningbo port, the second largest port in China, convenient
transportation and low cost, and close to Shanghai, convenient for customers to visit
our factory
Items No. φ | least radius of gyration | stretch rate | Maximum tensile rate | Hardness | length of rolled | ||
DIA | In | mm | Stretching rate | Kg | Lbs | Hardness | Roll |
2 | 0.79 | 20 | 1.5-3% | 0.3 | 0.7 | 90 | 400 |
3 | 0.98 | 25 | 1.5-3% | 0.7 | 1.6 | 90 | 400 |
4 | 1.38 | 35 | 1.5-3% | 1.2 | 2.7 | 85 | 200 |
5 | 1.57 | 40 | 1.5-3% | 2.0 | 4.3 | 85 | 100 |
6 | 1.97 | 50 | 1.5-3% | 3.2 | 7.0 | 85 | 100 |
7 | 2.17 | 55 | 1.5-3% | 4.1 | 9.0 | 85 | 100 |
8 | 2.56 | 65 | 1.5-3% | 5.0 | 11.0 | 85 | 100 |
9 | 2.95 | 75 | 1.5-3% | 6.8 | 15.0 | 85 | 50 |
10 | 2.95 | 75 | 1.5-3% | 7.7 | 17.0 | 85 | 50 |
12 | 3.94 | 100 | 1.5-3% | 12.2 | 27.0 | 85 | 30 |
15 | 4.72 | 120 | 1.5-3% | 17.7 | 39.0 | 85 | 30 |
18 | 5.71 | 145 | 1.5-3% | 25.4 | 56.0 | 85 | 30 |
20 | 6.30 | 160 | 1.5-3% | 31.3 | 69.0 | 85 | 30 |
