Red White Green Hardness 90a Pu V Belt 30m Per Roll For Ceramic Production Lines

چین Wuxi Jiunai Polyurethane Products Co., Ltd گواهینامه ها
چین Wuxi Jiunai Polyurethane Products Co., Ltd گواهینامه ها
Customer satisfaction products , good service !

—— Mr. Alcioni possamai

we are very impressed with the quality of the belts you produced.

—— Mr.Mike

your products are very popular in my markets.

—— Mr. jone

چت IM آنلاین در حال حاضر

Red White Green Hardness 90a Pu V Belt 30m Per Roll For Ceramic Production Lines

Red White Green Hardness 90a Pu V Belt 30m Per Roll For Ceramic Production Lines
Red White Green Hardness 90a Pu V Belt 30m Per Roll For Ceramic Production Lines Red White Green Hardness 90a Pu V Belt 30m Per Roll For Ceramic Production Lines Red White Green Hardness 90a Pu V Belt 30m Per Roll For Ceramic Production Lines Red White Green Hardness 90a Pu V Belt 30m Per Roll For Ceramic Production Lines

تصویر بزرگ :  Red White Green Hardness 90a Pu V Belt 30m Per Roll For Ceramic Production Lines

جزئیات محصول:
Place of Origin: China
نام تجاری: Jiuna
گواهی: ROHS
Model Number: A-13 / B-17 / C-22
پرداخت:
Minimum Order Quantity: 600 Meter
Packaging Details: Inner packing is plastic film .outer packing is carton
Delivery Time: Within 5 working days After receipt of your deposit
Payment Terms: T/T, 50% payment in advance ,50% balance before shipment
Supply Ability: 96.000 meters per Month
export port: shanghai
Factory: Wuxi city
توضیحات محصول جزئیات
عملکرد اصلی: انتقال درایو سختی: 90 ساحل A
مواد: PU طول: 30 متر / رول
تایپ کنید: تسمه V رنگ: هر رنگی
برجسته:

کمربند گرد سبز

,

کمربند گرد pu

,

سختی 90a تسمه pu v



Red White Green Hardness 90a Pu V Belt 30m Per Roll For Ceramic Production Lines





(1) Thermoplastic polyurethane material, easy to be melted jointed,100% pure polyurethane
(2) Reinforced by Polyester Cord or Steel Cord
(3) Temperature range -35 degree  - 80 degree
(4) Shore A hardness range 80A - 98A
(5)  With excellent resistance to flex, abrasion resistance, easy jointed and other characteristics. Widely used in textile, packaging, printing, machinery, electronic, glass, chemicals, ceramics and other industries, especially in the ceramic industry, widely used in the facilities line the glaze, polishing lines, and transmission line.
(6)  Specification including A, B, C , D, M , Z, widely used in ceramic industries with excellent abrasion resistance.



Product Technical Parameters :



Specification

X(mm)

H(mm)

Z(mm)

M/rolls

reinforced

arabesquitic

A

13

8

3.5

30

·

·

B

17

11

3.5

30

·

·

C

22

14

3.5

30

·

·

D

32

19

3.5

30

·

·

M

8

4



50





Z

10

5

3.5

50

·

·



Characteristics for PU V-section belt

excellent elasticity and damping characteristics

High tensile strength

With smooth surface v-belts

Color :red ,white

Hardness 90 shore A

Available with or without reinforced cord .

Replacement for conventional rubber V-belts , but more wear-resisting and can welding.

Red White Green Hardness 90a Pu V Belt 30m Per Roll For Ceramic Production Lines 0



Red White Green Hardness 90a Pu V Belt 30m Per Roll For Ceramic Production Lines 1Red White Green Hardness 90a Pu V Belt 30m Per Roll For Ceramic Production Lines 2Red White Green Hardness 90a Pu V Belt 30m Per Roll For Ceramic Production Lines 3Red White Green Hardness 90a Pu V Belt 30m Per Roll For Ceramic Production Lines 4

Products introduction



In addition , We are able to tailor Round and V-belts of different lengths and diameters - within a few days and with high quality.
